INTEL H610
CPU
Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
LGA 1700
Memory
2x DDR4, Maximum Memory Capacity 64GB
Memory Support DDR4 3200(OC)/ 2933(OC)/ 2666(OC)/ 2400(OC) MHz
Supports Intel® XMP 2.0 OC
Supports Dual-Controller Dual-Channel mode
Onboard graphics
1xVGA
1x HDMI™port
*HDMI™ port supports up to 4K@30Hz
*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.
Expansion slot
1x PCIe 4.0 x16 slot
1x PCIe 3.0 x1 slot
Storage
M.2 slot (Key M), type 2242/2280 (supports PCIe 3.0 x4 mode)
3x SATA 6Gb/s ports
RAID
Not Supports RAID
USB
*Front USB (Total 4 ports)
2x USB 3.2 Gen1 Type A
2x USB 2.0
*Rear USB (Total 6 ports)
2x USB 3.2 Gen1 Type A
4x USB 2.0
LAN
Realtek® RTL8111H 1G LAN
Audio
Realtek® ALC897 Codec
5.1-Channel High Definition Audio
Internal I/O
1x 24-pin Power Connector(ATX_PWR)
1x 8-pin Power Connector(CPU_PWR)
1x CPU Fan
3x System Fan
1x M.2 slots (Key-M)
3x SATA 6Gb/s ports
1x 2-Pin CLR_CMOS
1x 4-Pin BUZZER
1x Front Audio
1x COM_A Port
1x 9-Pin DEBUG_CON
1x TPM pin header(Support TPM 2.0)
LED Feature
4x Distributed Debug LED
Operating system
Support for Windows® 11 64-bit, Windows® 10 64-bit
Form factor
M-ATX
220mm x 185mm
