Name: MSI MAG A750BN PCIE5 III 80 PLUS Bronze PCIe 5.1 ATX 3.1 Non-Modular Power Supply
Brand: MSI
SKU: msi-mag-a750bn-pcie5-750w-power-supply-copy
Price: 89.00 AUD
Availability: InStock

MSI MAG A750BN PCIE5 III 80 PLUS Bronze PCIe 5.1 ATX 3.1 Non-Modular Power Supply

Wattage: 750 W
Efficiency: 80+ Bronze
Modular: Non-modular
Warranty: 36 mo
Product Name: MAG A750BN PCIE5 III
Model Name: TORX FAN 12CM
Weight (Card): 169 g
Radiator Compatibility: 120 / 140 / 240 mm
Efficiency Rating: 80 PLUS Bronze (up to 85%)
Fan Dimensions: 120 × 120 × 25.6 mm
Fan Size: 120 mm
Fan Bearing: Hydraulic Bearing
PSU Dimensions (D × W × H): 140 × 150 × 86 mm / 5.51 × 5.9 × 3.38 in
Bearing Type: Hydro-Dynamic Bearing
PFC Type: Active PFC
Rated Speed: 500 – 1800 ±15% RPM
Input Voltage Range: 100–240V~
Air Flow: 19.79 – 71.27 CFM
Power Output: 750 W
Static Air Pressure: 0.16 – 2.09 mm-H₂O
Power Excursion: 200%
Connector Type: 4-Pin PWM / DC
Input Frequency Range: 50–60 Hz
Life Expectancy: MTTF 150,000 hours (25 °C)
Protection: OVP, OCP, SCP, OPP, UVP
ATX (24-pin): 1
EPS (4+4-pin): 2
PCI-E 5.1 (16-pin): 1 (450 W)
PCI-E (6+2-pin): 3
SATA (15-pin): 3
Peripheral (4-pin): 2
