No overview available.

Form factor support

Mini-ITX

Side panel

Tempered Glass

Color

Black / White / Pink

Dimensions

481 mm (D) × 240 mm (W) × 501 mm (H) / 58 L

Materials

Steel, TG, Plastic, Fabric

Motherboard Compatibility

Support Motherboard Size: ATX / Micro-ATX / Mini-ITX, Back Connect Motherboard Support: ATX (BTF / Project Zero / Project Stealth)

PCI-e Expansion Slots

7

Expansion Drive Support

4 × 2.5" SSD or 3.5" HDD

I/O Ports

2 × USB-A 3.2 Gen 1, 2 × USB-C 3.2 Gen 2, 1 × Audio / Mic jack, 1 × Power Button

Fan Support

Top: 120 mm ×3 / 140 mm ×2, Side: 120 mm ×2 / 140 mm ×2, Front: 120 mm ×3 (with pre-installed Cross Flow Fan mounted),, 140 / 160 / 180 / 200 mm ×2 (requires removal of Cross Flow Fan), Bottom: 120 mm ×2, Rear: 120 mm ×1

Radiator Support

Top / Front: up to 280 mm / 360 mm, Rear: 120 mm, Side: up to 240 mm / 280 mm

GPU Clearance

≤ 420 mm, ≤ 360 mm with pre-installed Cross Flow Fan

CPU Cooling Clearance

≤ 170 mm

PSU Support

ATX, maximum length 200 mm

Cable Management Space

40 mm

Dust Filters

Top, Bottom, Front, Side

Pre-installed Fans

1 × TRYX Cross Flow Fan, 1 × TRYX ROTA 120 Fan
